Brand
Yike
Model
YD
Parameter classification
Parameter directory
YDL63
Vehicle parameters
Optional colors
White、Red、Pink、Blue、Green、Purple
Length*width*height(mm)
2705*1210*1590
Wheel base(mm)
1780
Front/rear wheel track（mm）
1010/1040
Body structure
3 doors and 3 seats
Min. Ground Clearance（full load)（mm）
≥148
Max. climbing ability（%）
≥20
Curb weight（kg）
365KG(Without battery)
Maximum indicator speed（km/h）
25/48
Maximum actual speed（km/h）
25/45
Power system
Motor type
AC motor
Rated power(w)
3000
Battery type
64v105ah
Battery type
Lithium Battery
Controller
AC controller
Range (loaded) based on flat road at a speed of 30km/h (km)
120km
Chassis System
Front suspension
McPherson independent suspension
Rear suspension
Non-independent suspension
Front brake type
Hydraulic disc brake 190
Rear brake type
Drum brake 180
Driving form
Rear drive
Reduction ratio
10;1
Steering mode
steering wheel
Parking brake type
Handbrake
Front wheel hub
Aluminum wheel (No logo)
Front wheel hubcap
—
Rear wheel hub
Aluminum wheel (No logo)
Rear wheel hubcap
—
Front tyre type
135/70R12
Rear tyre type
135/70R12
Electronic control system
Button start
—
Reboot
●
Central lock
●
Combination LCD meter
●
Media/USB interface/bluetooth
●
Rear seat USB interface
●
Power windows
●
Reversing video
●
Headlight
Certification mark
Taillight
Certification mark
Celling light
—
Heater
●
Air conditioner
—
Rake assist
●
Power-assisted steering gear
—
Steering wheel lock
●
Portable charger
●
Wiper
●
Spray
●
Electronic high and low speed
●
Hill assist
●
Speaker
1
Other configurations
Sun visor
—
Foot mat
●
Front three-point seat belt
Certification mark
Rear three-point seat belt
Certification mark/1
Seat
Imitated leather
External rear view mirror
Certification mark
Manual inside rearview mirror
Certification mark
Glass
Certification mark
Front license plate/steel
Body colour
Rear license plate/steel
—
Chinese and English label
●
Side reflector
—
Back reflector
●
Key
Mechanical key 1 /Remote key 1
