| Length(mm) | 6645 | Power motor Specification | Power motor model | TZ365XSB05 single stage,big torque electronic motor for Large slope Road |
| Width(mm) | 2400 | | Manufacture standard | CNAS /ECE standard for electric bus include all the spare parts |
| Height(mm) | 300 | | | |
| Wheel base(mm) | 3800 | | Type of Power motor | 1000NM single stage Permanent magnet synchronous motor
1000Nm |
| Tread F/R(mm) | 1830/1675 | | Motor rated power /Speed/torque
//(kW/r/min) | 90KW/1700rpm/500Nm IP67
|
Overhang F/R(mm)
/ | 1550/1295 | | Peak power of motor/Speed/Torque
//(kW/r/min) | 160KW/4500rpm/1000Nm IP67
|
Approach/Departure (°)
/ | 15/17 | | Fuel Type |
Pure electric |
Passenger load /seat
/ | 39/10-18 person | | | |
Chassis Manufacture | Monocoque | Max. Speed(km/h) | ≤70 |
Brake distance(m)
(v=30km/h) | ≤10 | Max. Grade Ability (%) | ≥15 |
| Power drive system position | Electrical drive motor rear mounted | Min. Turning Diameter (m) | ≤8 |
| Max Total Mass(kg) | 9000 | Curb Weight(Kg) | 5500 |
()
Minimum ground clearance (under full load) | >170mm | | |
