| Model | GXF20S | Curb weight | 2320kg |
Dimensions | 4050*1480*2100mm | Walking speed | ≥25Km/h |
Car size | 2800*1400*1400mm | Recharge mileage | ≤40Km |
Front track | 1250mm | Max. lift | 50m |
Rear track | 1250mm | Max. working pressure | 0.55Mpa |
Wheelbase | 2100mm(±10) | Min. turning radius | 5000mm |
Ground clearance | 190mm | Max. grade | ≤15° |
| Max. working flow | 600L/min | Tank volume | 2000L |
| Frame | Riveted frame | Tire | 185-70-14 (Chao yang) |
| Electronic control | 72V500A AC Controller / Optional |
Battery | 72V200Ah lead-acid maintenance-free battery / Optional |
| Motor | 72V10KW AC motor |
| Charger | Smart charger (The battery model determines the charger model) |
Charging time | 8-10 hours Temperature affects charging time |
Cab | Enclosed frame steel cab, glass doors, wipers, electronic display instrumentation, radio, adjustable seats, fifire extinguisher, reversing camera, electric fan. |
Seat | Leather Upholstered Seats, Leather Cushions |
Rearview mirror | Large fifield of view without dead angle rearview mirror |
Lights and Signals | Dual headlights + turn signals + brake lights + overall rear tail lights + reversing voice prompt |
Warning light | Long row highlight strobe type |
| Power configuration | Lifan 190 electric start gasoline engine + Huaqiu 600L pump |
| Fire equipment | Two dry powder fire extinguishers, one set of fireproof suit with helmet and rubber shoes, one shovel and fire axe, two fire hoses |
| Attachment configuration | On-board tool kit, fire wrench |
| Water spray | Universal high-pressure water cannon at the top of the car, sprinkler at the rear of the car |
| Water outlet control method | Manual control of fire high pressure water outlet |
| Steering method | Electric Power Worm Steering Gear |
| Braking System | Front and rear independent dual pipelines, vacuum-assisted hydraulic drum automatic brake system, auxiliary manual mechanical handbrake parking |
Front suspension | Load-bearing steering front axle, axle tube thickness 5mm, diameter 60mm, hydraulic drum brake, 220mm large diameter brake drum, spring steel plate with hydraulic damper for shock absorption |
Rear suspension | Load-bearing spring steel plate shock absorber system with hydraulic damper, the steel plate is 63mm wide, and a single piece is 8mm thick |
Rear axle | Full suspension oil brake high and low speed integrated rear axle, no less than 250mm arge diameter split brake drum, no less than 30 thick half shaft, no less than 76mm half shaft axle tube thickness 5mm, hydraulic drum brake |
