| Item | | ES-L2+2 |
| Power(optional) | | 48V5KW(Lead acid) | 72V5KW(Lithium battery) |
| Chassis frame | High strength sheet metal rectangular frame (electrophoresis + highlight) |
| Outline dimension | | 2950*1340*2130mm |
| Front / rear tread | | Front1005mm/Rear1075mm |
| Wheel Axle distance | | 1680mm |
| Ground clearance | | 170mm |
| Minimum turning radius | | 3.2m |
| Net weight | | 610kg |
| Maximum driving speed | 50km/h(Can be adjusted according to customer needs) |
| Climbing capacity | 25% |
| Standing slope performance | 25% |
| Endurance | 80-100km (flat road) |
| Braking distance | <3.5m |
| Motor voltage(Alternating current) | | 48V5KW | 72V5KW |
| Motor brand | KDS Motor |
| Electric control brand | | Borcart 48V350A | Borcart 72V450A |
| Battery | | Shengyang lead acid without maintenance 6*8V150AH | Guosheng 72v120ah lithium iron phosphate |
| DC converter | | High power non isolated DC-DC 48V/12V-300W | High power non isolated DC-DC 72V/12V-300W |
| Battery charger | | Preston intelligent vehicle charger 48V/25A,charging time < 8 hours (discharge rate 80%) | Standard lithium iron phosphate charger |
| Steering system | Bidirectional rack and pinion steering system with automatic clearance compensation function |
| Braking system | Zero crossing rear axle: four wheel hydraulic pressure brake, four wheel disc brake + electronic brake parking |
| Front suspension | Double swing arm and independent front suspension + coil spring + barrel hydraulic pressure shock absorber. |
| Rear suspension | Integral rear axle, speed ratio 16:1,coil spring damping + barrel hydraulic pressure damping + rear stabilizer bar |
| Tire specification | | DOT certification;Road tire 205/50-10(tire diameter 520mm)10 inch aluminum wheel hub |
| Ceiling | Frosted black square pipe frame + PP injection molding ceiling |
| Floor | Aluminum alloy profile anti-skid floor,high strength structure,corrosion resistance and aging resistance |
| Body of car | The front cover,seat barrel,body and rear tail cover are injection molded for automobiles;Frosted black square pipe ceiling column; |
| Seat | Integral foam forming cushion;High grade imported leather (optional) color separation;Reverse row seat can be turned over,including storage box |
| Instrument panel | Injection molding instrument panel, electric lock switch, double arm combination switch, gear switch, electronic hand brake switch, water cup holder; Dual USB data interface, 12V power supply, USB + type-C fast charging. The LCD electric vehicle combination instrument (including fault diagnosis information display) platform is an embedded multimedia touch LCD screen. Optional reverse image. |
| Rearview mirror | One manually adjustable and foldable exterior rearview mirror on the left and right |
| Lights and warning signals | Led front combination lamp (low beam lamp,high beam lamp,turn signal lamp,daytime running lamp,position lamp)
LED rear tail lamp (brake lamp, position lamp, turn signal lamp); Snail horn, reversing buzzer |
| Front windshield and wiper | DOT certified acrylic plexiglass;Optional tempered glass + wiper |
