serial number | project name | parameter |
Technical Parameters | Vehicle size | 4350×1500×2080mm |
Cabinet size | 2800×1400×560mm |
Rated occupants | 2 people |
Wheelbase | 2090mm |
Wheelbase | 1220/1200mm |
minimum ground clearance | 140mm |
Minimum turning radius | 5m |
Maximum operating speed | 30km/h |
Maximum grade | 10% |
Curb weight | 1100kg |
Rated load | 1200kg |
Driving range | 80km |
Charging time | 6-8h (discharge rate 80%) |
Electrical System | motor | 60V4000W DC motor |
controller | 60V36 tube DC electric control system |
Battery | 60V200 Leike water battery |
charger | Portable smart fully automatic charger |
lights and signals | Combined headlights, side turn lights, combined rear taillights, electric horn, reversing voice alarm |
Chassis | Frame | Overall welded frame + pickling phosphate electrophoresis paint |
Power transmission | rear drive, Continuously variable transmission system with forward and reverse gears |
turn | Circulating ball steering machine |
Front axle and suspension | Mini car front axle, leaf spring non-independent suspension, cylinder hydraulic shock absorber |
Rear axle and suspension | Mini car rear axle, leaf spring non-independent suspension, cylinder hydraulic shock absorber |
brake | With vacuum brake assist, front and rear drum hydraulic brakes, dual-circuit hydraulic brakes, parking brake device |
tire | Steel wheels, 165/70R12C vacuum double-coin tires |
Body configuration | paint | Premium automotive paint |
car body | Steel frame + steel plate bending and welding forming box |
dashboard | Blister molded instrument panel, LCD combination instrument (including current, voltage, speed, mileage, light and other signals) |
seat | One-piece seat (leather fabric + high resilience PU , with armrests) |
rearview mirror | One manual exterior rearview mirror on the left and right |
police light | Snail type police light |
switch | Ignition switch, light and wiper combination switch, front and rear reversing, warning light switch |
Steering column | Column with directional power assist |
steering wheel | Polyurethane foam steering wheel |
cabinet | The box body is made of steel plates that are bent and welded as a whole, with beautiful appearance and novel style. |
